| Conductor size |
Φ40 |
| Rated current |
AC 500A |
| Output voltage |
AC 500mV/500A (AC 1mV/A) |
| Accuracy |
|±0.5%rdg±0.1mV (50/60Hz)
|±1.0%rdg±0.2mV (40Hz~1kHz) |
| Phase Shift |
within ±1.0º (45~65Hz) |
| Withstand voltage |
AC 5350V for 5 seconds |
| Cable length |
Approx. 3m |
| Output connector |
MINI DIN 6pin |
| Operating temperature ranges |
0~50ºC, less than 85% RH (without condensation) |
| Output impedance |
Approx. 2Ω |
| Applicable standards |
IEC 61010-1:2001,
IEC 61010-2-032:2002 CAT.III 600V pollution degree 2 |
| Dimensions |
128(L) x 81(W) x 36(D) mm |
| Weight |
Approx. 260g |
| Accessories |
9095 (Portable case), Instruction manual, Cable marker |
| Option |
7146 (Banana Φ4 adjuster plug)
7185 (Extension Cable) |
