| Ranges |
0.1~19990Lux |
Accuracy
(23ºC±5ºC) |
Lux |
Accuracy |
| 200 |
|±(4% rdg+5 dgt) |
| 2000 |
|±(4% rdg+5 dgt) |
| 20000 |
|±(5% rdg+4 dgt) |
| Current Consumption |
2mA approx |
| Response Time |
2.5times / sec. |
Operating
Temperature Range |
0~50ºC Below 80% RH |
| Storage Temperature Range |
-10ºC~60ºC |
Angular Incident
Light Characteristics |
30º Less than ±3%
60º Less than ±10%
80º Less than ±30% |
Spectral Response
Characteristics |
JIS C1609 CLASS A |
| Power Source |
6F22 (9V) × 1 |
| Dimensions |
Meter:148(L) × 71(W) × 36(H)mm
Light Receiving Sensor:85(L)× 67(W) × 32(H)mm |
| Weight |
270g |
| Accessories |
Carrying Case
6F22 (9V)
Photocell Cover
Instruction Manual |
