| DC A |
| 20/100mA (Auto ranging) |
 |
|
±0.2%rdg±5dgt |
(0.00mA ~ 21.49mA) |
| |
±1.0%rdg±5dgt |
(21.0mA ~ 120.0mA) |
|
| Conductor size |
Ø6mm max. |
| Analog output |
Recorder: DC 1000mV against DC 100mA |
| Withstand voltage |
2210V AC for 5 seconds |
| Applicable standards |
IEC 61010-1, 61010-2-030 CAT.II 300V
IEC 61010-2-032
IEC 61326-1, 61326-2-2
IEC 60529 IP40 |
| Operating temperature & humidity |
-10 ~ +50ºC < 85% |
| Storage temperature & humidity |
-20 ~ +60ºC < 85% |
| Power source |
R6/LR6 (AA) (1.5V) × 4 |
| Dimensions |
111(L) × 61(W) × 40(D)mm : Display unit
104(L) × 34(W) × 20(D)mm : Sensor
700mm : Sensor cable |
| Weight |
Approx. 290g (including batteries) |
| Accessories |
9096 (Carrying case), LR6 (AA) × 4,
Instruction Manual, Calibration certificate |
| Optional |
7256 (Output cord) |
