KM 3124A High Voltage Insulation Tester

Qty

•	Permits a wide range of insulation testing up to 100GΩ at variable test voltage from 1kV to 10kV.
•	DC voltage output for recorders.
•	Output voltage is shown on the digital display.
•	After tests, automatically discharges the charges stored in the circuit under test.
•	Operated by rechargeable Nickel-Cadmium batteries.

DC Test Voltage	1k~10kV variable	1000V
Measuring Ranges (automatic change)	1.6GΩ/100GΩ (autoranging)	100MΩ
First Effective Measuring Ranges Accuracy	0.05~50GΩ	1~100MΩ
	\|±10% rdg
Other ranges Accuracy	\|±1% of scale length
Output Voltage and Set Voltage Indicate	DC 0~10kV \|±2%rdg±2dgt
Withstand Voltage	5000V AC for 1 minute
Power Source	Ni-Cd rechargeable battery (1.2V) × 8
Dimensions	200(L) × 140(W) × 80(D)mm
Weight	1.5kg approx.
Accessories	7082 (Lead for recorder) 7083 (Lead for battery charging) 7084 (Earth and guard leads) 8075 (120V) or 8080 (220V) (Battery charger) 9112 (Hard Carrying Case) Ni-Cd rechargeable battery × 8 Instruction Manual
