Measurement
Ranges |
Earth Resistance: 0~12 Ω/0~120 Ω/0~1200 Ω
Earth Voltage [50,60Hz]: 0~30V AC |
| Accuracy |
Earth Resistance: ±3% of full scale
Earth Voltage: ±3% of full scale |
| Overload Protection |
Earth Resistance: 276V AC for 10 seconds
across 2 of the 3 terminals
Earth Voltage: 276V AC for 1 minute |
| Safety Standard |
IEC 61010-1 CAT.III 300V Pollution Degree 2, IEC 61557 |
| Applicable Standards |
IEC 60529 IP54 |
| Withstand Voltage |
3700V AC for 1 minute |
| Power Source |
R6P (AA) (1.5V) × 6 |
| Dimensions |
105(L) × 158(W) × 70(D)mm |
| Weight |
600g approx. |
| Accessories |
7095A (Earth resistance test leads) × 1set
(red-20m, yellow-10m, green-5m)
8032 (Auxiliary earth spikes) × 1set
7127A (Simplified measurement probe) × 1set
R6P (AA) × 6
Neck strap
Instruction Manual
| Carrying Case |
: 9084 (Soft case) |
| |
: 9164 (Hard case) |
|
| Optional |
7100A (Precision measurement cord set)
|
