* Cannot be used for power measurement
| |
| |
| Conductor size |
Φ40 |
| Rated current |
AC 1000mA |
| Output voltage |
AC 100mV/1000mA (AC 100mV/A) |
| Accuracy |
|±1.0%rdg±0.1mV (50/60Hz)
|±2.0%rdg±0.1mV (40Hz~1kHz) |
| Withstand voltage |
AC 3540V (50/60Hz) for 5 seconds |
| Cable length |
Approx. 2m |
| Output connector |
MINI DIN 6pin |
| Operating temperature ranges |
0~50ºC, less than 85% RH (without condensation) |
| Output impedance |
Approx. 200Ω |
| Applicable standards |
IEC 61010-1,
IEC 61010-2-032,
CAT.III 300V pollution degree 2 |
| Dimensions |
128(L) x 81(W) x 36(D) mm |
| Weight |
Approx.240g |
| Accessories |
9095 (Portable case), Instruction manual |
| Option |
7146 (Banana Φ4 adjuster plug)
7185 (Extension Cable) |
|
|
