HZ K109-31 Polishing Pads

  • HZ K109-31 Polishing Pads

HZ K109-31 Polishing Pads

    • S$9.21

       (Ex Tax: S$8.45)
  • Availability: 2-3 Days

Metal working > Milling machines / Pattern cutters
K-109 MINI ROUTER



Rotation speed 7000 to 16500rpm
Standard tip K-109-10
Rated voltage / frequency 100 VAC 50 / 60 Hz
Power consumption 20 W
Rated time 15 minutes
Grip outer dia. 18 mm ¢ (at smallest part)
Weight 160 g (not including cable & bit)
■ Power cable: 1.3m

#
#
#
#
Note Continuous operation which exceeds 15 min. can cause a motor failure, etc.
Even on & off at 1 to 2 minute intervals is considered continuous.


■ K-109
Part No. Name Sizes
K-109-10 Cutter Tip #
K-109-11 #
K-109-12 #
K-109-20 Polishing Pad #
K-109-30 #
K-109-31 #
K-109-32 #
K-109-40 Endmill #
K-109-41 #
K-109-50 Drill #
K-109-51 #
K-109-52 #
K-109-53 #
K-109-54 #
K-109-55 #
K-109-60 Brush #
K-109-61 #
K-109-62 #
K-109-63 #


#

#

Optional parts
K-109-69 BIT SET
■ For K-109
#
K-109-59 DRILL BIT SET
■ For K-109
#
W-521-2 DRILL BIT SET
■ For K-109
#
